Eikon

Eikon Personal Monitor Headphone Amplifier | EMPAMP4 Compact Studio & Stage

Eikon Personal Monitor Headphone Amplifier | EMPAMP4 Compact Studio & Stage

EMPAMP4

21 in stock

$199.00 AUD
$199.00 AUD $199.00 AUD
Sale Sold out

Eikon Personal Monitor Headphone Amplifier

The MPAMP4 compact headphones amplifier features a pass-through MIC/LINE input and a STEREO/MONO monitor input with individual level controls. It is very useful in recording studios or on stages when you need to mix and listen to two sound sources together.

This headphones amplifier is designed for use with all types of in-ear or over-ear headphones and therefore offers maximum flexibility for personal monitoring. It is typically used to combine your voice or instrument with other members of the band during a live concert or to listen to pre-recorded tracks during recording, allowing for customized mixing of the monitor signal. The THRU connection allows you to directly feed your voice or instrument to other live or recording equipment.

INPUT SECTION

Connectors

1 x COMBO, 2x 1/4" JACK unbalanced

Inputs

1x MIC/LINE 1x MONITOR (stereo/mono)

Input Impedance

10 Kohm (LINE/MONITOR), 1 Kohm (MIC)

Max Input Level

+20 dBu (MONITOR), +10 dBu (LINE), -15 dBu (MIC)

OUTPUT SECTION

Connectors

1x XLR-M, 1x 1/4" or 1/8" JACK stereo

Outputs

1x MIC/LINE THRU, 1x HEADPHONES stereo

Max output 32ohm

2x 100mW

Max output 600ohm

2x 100mW

Load Impedance

min 16 ohm

Max Gain

+8 dB (MONITOR), +14dB (LINE), +35dB (MIC)

SYSTEM PERFORMANCE

Distortion (THD)

0.02%

Noise

< -98 dBu unweighted

Frequency Response

< 20 Hz - 20 KHz (-3dB)

POWER SUPPLY

Connector

USB Type B

AC/DC Adapter Input

100-240V ~ (±10%) 50/60Hz

AC/DC Adapter Output

5V-1A (5W)

Supplied Cable

1.2m USB Type A - Type B

GENERAL

Controls

MIC/LINE LEVEL, MONITOR LEVEL, MIC/LINE SELECTOR, GND LIFT

Indicators

Power ON

Dimensions (WxHxD)

160 x 52 x 106mm

Weight

0.52kg (main w/out cable)

Download User Manual Here
